PCSL Sedimentaion basket plate centrifuge
Principle:
PCSL-N Plate Type High Speed Sedimentation Basket Centrifuge is a kind of medium and fine particles of solid liquid separation, PCSL800-N is widely used in the solid phase of small particle size, relatively low concentration, viscosity difficult to separate materials. Mainly used in chemical, food, light industry, pharmaceutical, biological products and other fields.
PCSL-N Plate Type High Speed Sedimentation Basket Centrifuge is a kind of medium and fine particles of solid liquid separation, PCSL800-N is widely used in the solid phase of small particle size, relatively low concentration, viscosity difficult to separate materials. Mainly used in chemical, food, light industry, pharmaceutical, biological products and other fields.
PCSL-N Plate Type High Speed Sedimentation centrifuge is a continuous operation, intermittent discharge of solid settling separation equipment, control with frequency converter start or brake, suitable for general occasions or proof occasions.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Principle and structure
Drive motor pass power directly to the centrifuge bowl, make its rotation and increase speed, leave the suction
tube moves to bowl block liquid surface, when the bowl speed up to feed rate, open inlet valve the material from the upper feeding tube into the bowl, under the action of centrifugal force and solid particles to the bowl wall motion, and piled into sediment, over a period of time after settling separation, surface cleaning fluid can use left radial movement of the liquid pipe using the tangential velocity leading out, flow to the liquor tank through a pipe.
When the sediment in the inner wall reaches a certain thickness, the dregs shall be removed by manual method after shutdown, and a working cycle shall be completed by the centrifuge.
Technical parameters
| Model | PCSL600-N | PCSL800-N | |
| Bowl | Inner diameter mm | 600 | 800 |
| Effective height mm | 300 | 400 | |
| Filtration area ㎡ | 0.52 | 1 | |
| Effective volume L | 35 | 100 | |
| Max.loading Kg | 40 | 130 kg | |
| Speed r/min | 2975 | 0-1800 r/min | |
| Max. Separating factor | 2800 | 1450 | |
| Motor power kw | 5.5 | 5.5 | |
| Dimension L*W*H mm | 1300*1300*1220 | 1400X1400X1200 | |
| Weight | 1250 | 1350 | |
