Vibration Dryer
Controlled oscillation removes surface moisture from bulk solids, granules, textiles and assembled components, with adjustable frequency and amplitude, variable airflow and straightforward integration into conveyor or batch lines. PLC-enabled controls and quick-change screens enable continuous inline operation that shortens drying cycles, increases throughput and lowers operational costs through reduced energy use and fewer maintenance interruptions.
Main performance
● Because the hot air passes through the layer of raw material several times and acts counter motion towards the raw material, the heat exchanger is fully preferment and thermal efficiency is high.
● The structure ls compact and it occupies small area.
● The stay time of raw material in the helix bed can be adjusted and the operation is very convenient.
● The raw material acts the motion if circle at helix bed from up to low,at the same the equipment can jump itself, so the contact surface between hot air and raw material is increased too and the dry effects is strengthened.
● The equipment is suitable for continuous operation because of continuous feeding and discharging raw material. Meanwhile it is easy to meet the requirements of “GMP”
● It does not damage the surface and shape of raw material basically.It can not only maintain the roundness of pill but also decrease the rate of pills.
Technical parameters
| Spec | unit | LZG-10 | LZG-1.2 | LZG-14 | LZG-16 | LZG-1.8 |
| Diameter | mm | 1000 | 1200 | 1400 | 1600 | 1800 |
| Power | kw | 2×0.75 | 2×0.75 | 2×15 | 2×1.5 | 2×2.2 |
| Over all dimensions | m | 12×12×2.7 | 1.4×14×2.7 | 1.6×1.26×3 | 1.8×18×33 | 2.0×2.0×3.3 |
| Weight | kg | 1400 | 1680 | 2800 | 3100 | 3800 |
| Production capacity | kph | 80-120 | 120-200 | 200-280 | 280-250 | 350-450 |
| Temperature of air intel | ℃ | 60-200 | 60-200 | 60-200 | 60-200 | 60-200 |
| Air amount | M3/h | 1487 | 2380 | 3721 | 4482 | 5930 |
| Power of fan | kw | 5.5 | 7.5 | 15 | 18.5 | 22 |
Contact us to customize machines, We are committed to forging great equipment with craftsmanship, protecting health with technology, bringing Chinese equipment to the world, and contributing to global health.
